3D Power Level Scanner

3D Power Level Scanner

Product Details:

  • Supply Ability : 10 Unit Per Week
80000 INR/Unit
X

Price And Quantity

  • 1 Unit
  • 80000 INR/Unit

Trade Information

  • 10 Unit Per Week
  • 4 Week

Product Description

We are engaged in offering our clients a high quality 3D Power Level Scanner, which measures multiple points on a material's surface, providing continuous and non-contact inventory volume measurement. Our offered 3D Power Level Scanner is available in various specifications to meet the diverse needs of the clients. This scanner uses low-level pulses to map the exact, three-dimensional shape of the contents of a tank or other container.



Technical Data Sheet :

Housing and Antenna

Painted aluminum die casting

Output variable

Output signal/ Communications

4-20mA/ HART/ RS485/ MODBUS/ TCP-IP/ GSM-GPRS/ Wireless Antenna/ LAN networking/ Profibus

Load 4-wire sensor

Max. 500 Ohm

Ambient / Process conditions

Ambient

-40-+-+185 oF (-40---+85oC)

Relative Humidity

95%

Vessel Pressure

-0.2bar---+3bar

Process Temperature

-40---+212oF (-40-+100oC)- Standard Varlants except Volcan
-40---+392oF (-40---+200oC)- HT varlant of each model and Volcan

Local Display

For Models S/ M/ MV(If required)/ MVL(If required)/ VOLCAN
4 lines X 20 characters with 4 keys (Indicator/ Local Panel on request)

Power Supply-4-wire

Supply Voltage

20-32 VDC (Universal Supply on request)

Power consumption

Max 1.5W @ 24VDC

Electrical protective measures

Protection

1P67 according to IEC 60529

Approvals

ATEX / FM / CSA /IECEx /CE / EMC, NSR / FCC

Measurement Characteristics

Frequency

2-10 KHz

Beam angle

30-70 degrees
